The Bently Nevada 3300/40-13-01-01-00-00 is an eccentricity monitor designed to measure shaft bow during slow-roll operation
Бренд :
Bently Nevadaномер части :
3300/40-13-01-01-00-00Масса :
1 kgИзмерение :
22.9 × 5.1 × 33 cmСтрана происхождения :
USAКод ТН ВЭД :
8537101190Описание :
Eccentricity Monitor
|
GET THE BEST PRICE |
SALES CONTACT |
|
Contact Person |
Frida |
|
|
|
|
☎ Mobile / WhatsApp |
Product Overview
The Bently Nevada 3300/40-13-01-01-00-00 is an eccentricity monitor designed to measure shaft bow during slow-roll operation. It helps operators observe fixed mechanical bow, temporary thermal bow and rotor sag caused by gravity while machinery is at rest or turning at low speed. This configuration measures one eccentricity channel and provides both direct and peak-to-peak indications. Its selected range is 0–500 µm peak-to-peak and 500-0-500 µm direct. The monitor works with 3300 or 7200 Proximitor systems at 200 mV/mil and also processes a Keyphasor signal for rotational reference.
Order Number Breakdown
3300/40 — Eccentricity Monitor
13 — 0–500 µm peak-to-peak range and 500-0-500 µm direct range
01 — 3300 or 7200 Proximitor systems; 200 mV/mil sensitivity
01 — Epoxy-sealed alarm relay option
00 — Agency approval not required
00 — No intrinsic safety barriers
Technical Information
|
Parameter |
Value |
|
Manufacturer |
Bently Nevada |
|
Product Line |
3300 System |
|
Ordering Number |
3300/40-13-01-01-00-00 |
|
Product Type |
Eccentricity Monitor |
|
Measured Variable |
Shaft eccentricity and rotor bow |
|
Measurement Channel |
1 eccentricity channel |
|
Eccentricity Indications |
Direct and peak-to-peak |
|
Peak-to-Peak Range |
0–500 µm |
|
Direct Range |
500-0-500 µm |
|
Accepted Signal Inputs |
One eccentricity proximity signal and one Keyphasor signal |
|
Compatible Proximitor Systems |
3300 or 7200 Proximitor systems |
|
Input Sensitivity |
200 mV/mil (8 V/mm) |
|
Proximity Input Impedance |
10 kΩ |
|
Keyphasor Input Impedance |
90 kΩ |
|
Direct Frequency Response |
0–10 Hz (0–600 cpm) |
|
Alarm Relay Option |
Epoxy-sealed |
|
Intrinsic Safety Barrier Option |
None |
|
Nominal Power Consumption |
1.5 W |
|
Signal-Conditioning Accuracy at 25°C |
±0.33% of full scale typical; ±1% maximum |
|
Recorder Outputs |
+4–20 mA, +1–5 VDC or 0 to −10 VDC |
|
Recorder Output Channels |
Separate direct and peak-to-peak outputs |
|
Voltage Output Impedance |
100 Ω |
|
Minimum Voltage Output Load |
10 kΩ |
|
4–20 mA Output Load |
0–600 Ω |
|
Display Resolution |
Within ±1.6% of monitor full scale |
|
Operating Temperature |
0°C to +65°C |
|
Storage Temperature |
−40°C to +85°C |
|
Relative Humidity |
Up to 95%, non-condensing |
|
Rack Requirement |
One rack position |
Benefits&Features
• Measures shaft eccentricity continuously during slow-roll operation
• Displays both direct and peak-to-peak eccentricity values
• Provides a 0–500 µm peak-to-peak measurement range
• Provides a 500-0-500 µm direct eccentricity range
• Supports 3300 and 7200 Proximitor systems
• Processes eccentricity and Keyphasor input signals
• Displays probe gap and Keyphasor threshold information
• Provides adjustable Alert and Danger alarm setpoints
• Offers separate recorder outputs for direct and peak-to-peak values
Application Areas
-Shaft bow monitoring during turbine slow-roll operation
-Thermal bow observation during machine startup and shutdown
-Gravity-induced rotor sag monitoring on large rotating equipment
-Eccentricity monitoring on turbines, generators and compressors
-Rotating and reciprocating machinery using a Keyphasor reference signal
Main brands
No.
Brand
Main Product Lines
1
ABB
DSQC Series industrial robot parts; Bailey INFI 90; DCS
2
Honeywell
51 Series; MU Series; MC Series; TC Series; CC Series
3
General Electric (GE)
IC693 Series; IC697 Series; IC695 Series; DS200 Series
4
PLC
1756 Series; 1747 Series; 1746 Series
5
Schneider Electric
140 Series
6
Bently Nevada
3500 Series; 3300 Series; 330180 cables
7
Foxboro
FBM203; FBM204; FBM217; FBM231; FCP240; FCP270
8
Westinghouse
1C Series; 5X Series
9
Triconex
3008; 3511; 3625; 3664; 3721; 3700A
10
Siemens
6DD Series; 6DP Series; 6ES5 Series; 6DR Series; 6GK Series
Frequently Asked Questions
1. What does the 3300/40-13-01-01-00-00 measure?
It measures shaft eccentricity or rotor bow during slow-roll operation. The monitor provides direct eccentricity and peak-to-peak eccentricity indications.
2. What are the measurement ranges of this configuration?
The “13” option provides a 0–500 µm peak-to-peak range and a 500-0-500 µm direct range.
3. Which Proximitor systems are compatible with this monitor?
The “01” input option supports 3300 or 7200 Proximitor systems with a scale factor of 200 mV/mil, equivalent to 8 V/mm.
4. Why does the monitor use a Keyphasor signal?
The Keyphasor signal supplies a once-per-revolution reference. The monitor uses this reference when processing eccentricity measurements and determining the rotor’s direct and peak-to-peak movement.
5. Which recorder outputs are available?
The recorder outputs can be programmed for +4–20 mA, +1–5 VDC or 0 to −10 VDC. Separate outputs are provided for the direct and peak-to-peak measurements.
